71806 C P4A GA

Ask Lasest Price
Brand Name :	ACBB
Model Number :	71806 C P4A GA
Certification :	ISO9001 IATF16949

Add to Cart

Product Details
Company Profile

71806 C P4A GA

Angular Contact Ball Bearing 71806 C P4A GA (in addition to DB, DT, TBT, QBC and other matching methods) is mainly used on high-speed motor spindles. The operating speed reaches 30000 to 36000 rpm. Imported materials, imported G5 grade steel balls, and Kluberspeed NBU15 grease are used, which have the advantages of high rigidity, high precision, high speed, etc.

718 Series Angular Contact Ball Bearing
Bearing No	Dimensions(mm)			rsmin	rs1min	(KN) BasicRatedload		(RPM) Ball speed limit		(RPM) Ceramic Ball limit speed		(N) Preload
Bearing No	d	D	B	rsmin	rs1min	Cr	Cor	Grease Lubrication	Oil Lubrication	Grease Lubrication	Oil Lubrication	A	B	C
71800C	10	19	5	0.30	0.10	1.90	0.98	75000	120000	95000	160000	7	23	54
71800AC	10	19	5	0.30	0.10	1.90	0.98	70000	110000	85000	140000	8	31	80
71801C	12	21	5	0.30	0.10	2.08	1.18	67000	100000	85000	140000	7	25	58
71801AC	12	21	5	0.30	0.10	1.96	1.12	60000	90000	75000	120000	8	33	85
71802C	15	24	5	0.30	0.10	2.28	1.50	56000	85000	70000	110000	8	27	63
71802AC	15	24	5	0.30	0.10	2.16	1.40	50000	75000	63000	95000	8	34	91
71803C	17	26	5	0.30	0.10	2.32	1.60	50000	75000	67000	100000	8	26	64
71803AC	17	26	5	0.30	0.10	2.20	1.53	48000	70000	56000	85000	10	33	95
71804C	20	32	7	0.30	0.10	3.80	2.65	43000	63000	53000	80000	15	50	114
71804AC	20	32	7	0.30	0.10	3.65	2.50	38000	56000	45000	67000	18	70	174
71805C	25	37	7	0.30	0.10	4.15	3.20	36000	53000	45000	67000	16	54	123
71805AC	25	37	7	0.30	0.10	3.90	3.00	32000	48000	38000	56000	18	72	181
71806C	30	42	7	0.30	0.10	4.40	3.65	30000	45000	38000	56000	16	56	129
71806AC	30	42	7	0.30	0.10	4.15	3.40	28000	43000	34000	50000	18	73	189
